WINDOWS

ES-H340

TYPE
Hung
BRAND
Prestige®

The ES-H340 is a 3 3/8” impact rated, thermally broken, single-hung window, designed to meet the most stringent architectural standards. The ES-H340 is suitable for both residential and commercial applications.

Designed for the USA market

FEATURES
Hurricane Resistant Hurricane Resistant Thermally Broken Thermally Broken

System Description

Small and large missile impact rated Maximum size: O/X equal: 54” width x 78” height , O/X equal with ½ shims: 43” width x 96” height , O/X unequal: 39” width x 81” height Frame depth: 3 3/8” Tested water infiltration: 12 psf. Tested design load: +80/-90 psf. U-value: 0.48 on insulating laminated SB 70 SHGC: 0.21 on insulating laminated SB 70

Features

Ultralift spiral balances Snap and sweep lock Thermally broken frame Flange or equal leg frame

Related Documents

Datasheet Installation Guide Brochure Miami Dade County
Notice of Approval NFRC Certificate
