Prestige
ES-SGD1010T
Hurricane Resistant
Thermally Efficient
The ES-SGD1010T is an impact-rated sliding glass door with minimal sightlines. This narrow door features less aluminum and more glass than others allowing a clearer view.
System Description:
- Minimalist sliding glass door.
- Large missile impact. · Frame depth:
- Standard and subsill: 5 3/8″ (2 track), 8 3/16″ (3 track), 11 1/16″ (4 track), 13 7/8″ (5 track).
- Cast in sill with box: 8 3/8″ (2 track), 11 1/4″ (3 track), 14″ (4 track), 16 13/16″ (5 track)
- Designed for 9/16″ laminated glass,1 5/16″ insulated laminated glass and 1 1/8″ insulated glass.
- Sill height: 1 7/8″.
- Interlocks sight line: 1 1/8″.
Features:
- Narrow door with minimalist sightlines.
- Multiple panel configurations.
- Removable sill riser.
- Standard contemporary handle & turn lever.
- Multiple options of frame sill (standard, cast-in sill and subsill).
- Pocket configuration.
- 4 types of reinforced interlocks.
